Hafele DL7600 Digital Lock (Art No: 499.21.180)





  • Warranty:2 years
  • Mode of entry: Bluetooth Key, Fingerprint, Smart Card, Pin and Mechanical Key
  • Capacity 100 Fingerprints, 100 Keycards, 1 Master password & 10 User passwords
  • Registering, Managing and Checking history on Häfele Smart Lock APP
  • Manage by master PW and User PW
  • Double verification, combine 2 in 3 verification ways to unlock (FP/FW/keycard)
  • Prevent mischief and hacking function
  • Auto and manual locking mode
  • Smart-home integration using Z-wave module
  • Door thickness:35 – 60mm


  • Fingerprint
  • Key card
  • Password
  • Mechanical key

Appliance door type

  • Wood door


  • Matt Black


  • Al, Zn, ABS

Dim. (W x D x H)

  • Front dimensions: 76 x 25 x 341 mm (include handle)
  • Back dimensions: 80 x 27 x 359 mm (include handle)


  • Away mode / Defense mode to increase security for your house in case no one home
  • Auto / Manual locking mode is changable
  • Managed by master password and user password
  • Häfele Smart Lock APP: Open on smartphone App via Bluetooth; Setting easier; Checking history
  • Double verification function by combine 2 in 3 access ways (Fingerprint / Password / Key card)
  • Private mode / Double locking mode can be activated from inside
  • A password can be entered with a random number to prevent stealing
  • Voice guide feature (English / Chinese)
  • Smart home intergration with Z-wave module (optional)
  • Low-battery warning by sound

Main voltage

  • 6V (alkaline battery 1.5V x 8ea, AA size)

Operating temperature range

  • from -25°C to +55°C

Door thickness
35 – 60 mm
